The METAL X

A Breakthrough in Metal 3D Printing

From the company that revolutionized 3D printing with composite carbon fiber, comes a leap in additive metal manufacturing. The Metal X greatly accelerates innovation, delivering metal parts overnight using a new technology at a fraction of the cost. Leave 20th century manufacturing in the dust and create anything from industrial replacement parts to injection molds to working prototypes.

Request a Quote ›

$14.07

part cost

100 μm

resolution

pump impeller

$12.56

part cost

80 μm

resolution

CAMSHAFT Sprocket

$45.93

part cost

50 μm

resolution

injection mold

$33.51

part cost

50 μm

resolution

weight-optimized engine bracket

markforged

ADAm

The intersection of 3D printing and metal injection molding, ADAM (atomic diffusion additive manufacturing) is an all new way to build metal parts.

Design

CAD your part, upload the STL, and select from a wide range of metals. The Eiger software does the rest making printing the right part easy.

Green Part

Just like metal injection molding, as-printed parts are “green” and scaled up to account for shrinkage during sintering. In this state the parts can be easily polished by hand.

Sinter

Green Parts go through a washing stage to remove some of the binder. They are then sintered in a furnace and the metal powder fuses into solid metal.

Final Part

Pure metal and up to 99.7% dense, the final parts are ready for use. They can be processed and treated just like any other metal parts.

Print with

Stainless Steel 17-4 & 316L

17-4 stainless steel combines high strength, corrosion resistance, and hardness, making it widely used in aerospace, medical and petroleum industries. We use it for assembly fixtures and tooling on the Mark X.

Also known as marine grade stainless steel, 316L stainless steel exhibits very good corrosion resistance and excellent weldability.

Request More Information ›

Print with

Aluminum6061 & 7075beta

As a general purpose aluminum, 6061 combines good machinability, strength, and weldability. It can additionally be anodized with a good finish. We use it for many of the machined components in the Mark X.

7075 Aluminum is one of the strongest aluminum alloys. With good fatigue strength and a high strength-to-weight ratio, this alloy is stronger than common structural steels (A36, 1018). We use it on the kinematic coupling in the bed of the Mark X. It's also common in aerospace and automotive racing.

Request More Information ›

Print with

Tool SteelA-2 & D-2beta

A-2 tool steel is air-hardened with excellent impact resistance. We use it for punches, dies, and form tooling on the Mark X.

The high carbon and chromium content of D-2 tool steel provides great hardness and abrasion resistance (but not as tough as A-2). D-2 is often used for cutting tools.

Request More Information ›

Print with

InconelIN Alloy 625beta

Inconel's strength combined with its impressive heat resistance makes it ideal for heat and pressure shielding applications. This Nickel-based superalloy is commonly used in jet engines and medical applications, and is very hard to machine. It is also very chemically resistant.

Request More Information ›

Print with

TitaniumTi-6Al-4Vbeta

Bearing the highest strength-to-weight ratio of any metal, Titanium 6-4 is ideal for lightweight applications and has both high tensile strength and fatigue resistance. This bio-compatible material is widely used in medical applications such as orthopedic joint replacements.

Request More Information

quality assurance

In-Process-Inspection

The Metal X gives you breakthrough quality and precision in printing. Scan your parts mid-print using our cloud-based Eiger software and a laser sensor affixed to the print head. Ensure dimensional accuracy at the most critical tolerances at any point in your print.

1μm

Measurement
Accuracy

50μm

Scanning
Resolution

Industry Leading

software

Quickly go from CAD to part with our powerful and easy to use Eiger software. We do all the math for you - from scaling up for sintering to calculating part cost, weight, and print time. Just upload your STL, pick a metal, and press print.

Get a Trial ›

markforged approved

Furnaces

Over 30 years of metal injection molding development has resulted in a diverse array of sintering furnaces for processing green parts. Any of these will work, but here are a few recommendations.

The Tube

Affordable, reliable and repeatable. Ideal for prototyping and small part production.

Request More Info ›

The Workhorse

Same wide range of materials as the starter tube, but with a larger hot-zone for bigger parts.

Request More Info ›

The Big Box

A build volume that fits the largest parts with room to spare and unlocks batch production.

Request More Info ›

Mass Production

Designed for volume production and supporting all metals, this furnace can handle the output of 100 Metal X’s.

Request More Info ›

the metal x

tech specs

BUILD VOLUME

250 mm x 220 mm x 200 mm

FOOTPRINT

575 mm x 467 mm x 1432 mm

z layer resolution

50 micron

Laser Scanning Resolution

50 micron

Laser measurement accuracy

1 micron

stainless steel

17-4 Stainless Steel
316L Stainless Steel

aluminum

6061 AluminumBeta
7075 AluminumBeta

inconel

IN Alloy 625 (Beta)

tool steel

A-2 Tool SteelBeta
D-2 Tool SteelBeta

TITANIUM

Ti-6Al-4VBeta

other materials

Looking for something else?
contact us ›

security

Single Sign-On
Two-Factor Authentication

productivity

Printer Fleet Management
Organization Admin Portal

software delivery

Cloud-Based
Local Storage
Fully On-Premiseoptional

early-access updates

Early Access to New Design Features & Printing Capabilities

Laser measurement accuracy

1 micron

success plan

Extended service and warrantyoptional

training

Onsite advanced design training with a Markforged engineeroptional

Technical Specifications

build volume

250 mm x 220 mm x 200 mm

footprint

575 mm x 467 mm x 1432 mm

Materials

17-4 Stainless Steel
316L Stainless Steel
6061 Aluminum (Beta)
7075 Aluminum (Beta)
A-2 Tool Steel (Beta)
D-2 Tool Steel (Beta)
IN Alloy (Inconel) 625 (Beta)
Titanium Ti-6Al-4V (Beta)

inspection parameters

50 micron beam diameter
1 micron Z resolution

z layer resolution

50 micron

Software features

Single Sign-On
Two-Factor Authentication
Organization Admin Portal
Early Access to New Features

Software delivery

Cloud-based
Local Storage

added feature options

Software delivery

Fully On-premise Contact for more info ›

success plan

Extended service and warranty
Onsite advanced design training with a Markforged engineer

The METAL X

A Breakthrough in Metal 3D Printing

$14.07

100 μm

$12.56

80 μm

$45.93

50 μm

$33.51

50 μm

markforged

ADAm

The intersection of 3D printing and metal injection molding, ADAM (atomic diffusion additive manufacturing) is an all new way to build metal parts.

Print with

Stainless Steel 17-4 & 316L

Print with

Aluminum6061 & 7075beta

Print with

Tool SteelA-2 & D-2beta

A-2 tool steel is air-hardened with excellent impact resistance. We use it for punches, dies, and form tooling on the Mark X. The high carbon and chromium content of D-2 tool steel provides great hardness and abrasion resistance (but not as tough as A-2). D-2 is often used for cutting tools.

Print with

InconelIN Alloy 625beta

Inconel's strength combined with its impressive heat resistance makes it ideal for heat and pressure shielding applications. This Nickel-based superalloy is commonly used in jet engines and medical applications, and is very hard to machine. It is also very chemically resistant.

Print with

TitaniumTi-6Al-4Vbeta

Bearing the highest strength-to-weight ratio of any metal, Titanium 6-4 is ideal for lightweight applications and has both high tensile strength and fatigue resistance. This bio-compatible material is widely used in medical applications such as orthopedic joint replacements.

quality assurance

In-Process-Inspection

The Metal X gives you breakthrough quality and precision in printing. Scan your parts mid-print using our cloud-based Eiger software and a laser sensor affixed to the print head. Ensure dimensional accuracy at the most critical tolerances at any point in your print.

Industry Leading

software

Quickly go from CAD to part with our powerful and easy to use Eiger software. We do all the math for you - from scaling up for sintering to calculating part cost, weight, and print time. Just upload your STL, pick a metal, and press print.

markforged approved

Furnaces

Over 30 years of metal injection molding development has resulted in a diverse array of sintering furnaces for processing green parts. Any of these will work, but here are a few recommendations.

the metal x

tech specs

Technical Specifications

added feature options

Follow Us

Get In Touch

A-2 tool steel is air-hardened with excellent impact resistance. We use it for punches, dies, and form tooling on the Mark X.

The high carbon and chromium content of D-2 tool steel provides great hardness and abrasion resistance (but not as tough as A-2). D-2 is often used for cutting tools.
