The FX20 brings the Digital Forge and Continuous Fiber Reinforcement to a new realm of parts, problems, and industries.
Massive Builds, Faster
The FX20 pairs size and throughput to make larger builds at incredible speeds, delivering the transformational benefits of The Digital Forge at a new scale.
Functional Parts
from Factory to Flight
Built for everything from performance tooling and fixtures to flight-ready production parts —
the FX20 can reinforce ULTEM™ 9085 with continuous carbon fiber.
Production-Ready Performance
A precision-designed, sensor-driven machine delivers
breakthrough reliability and performance with a simple user experience.
The biggest, fastest, and most sophisticated 3D printer we’ve ever built.
見積もりを依頼Specs
Physical Dimensions
| 幅 | 1325 mm |
| 奥行き | 900 mm |
| 高さ | 1925 mm |
| 重量 | 453 kg / 1000 lbs |
ビルド容量
| 幅 | 525 mm |
| 奥行き | 400 mm |
| 高さ | 400 mm |
Printer primary Specs
- プリント
- Fused Filament Fabrication, Continuous Fiber Reinforcement
- Z 軸の分解性能
- 50 μm - 250 μm
- プリント媒体
- Polymer Filament, Continuous Fibers
- パーツの内部形状
- Closed Cell Infill with Continuous Fiber Reinforcement
- プリント ベッド
- Precision Machined Aluminum
材料
システムの詳細
About the FX20
The FX20 is the largest and most precise machine Markforged has ever produced.
It features an 80L heated build chamber and massive precision ground vacuum bed with reusable print sheets. The motion control system offers closed loop control through precision linear encoders, and is tuned to move the 3kg print head rapidly and accurately. FX20’s turbo mode builds parts faster than any Markforged machine, while new XL spools offer four times the material without spool changeover.
The FX20 is remarkably easy to use. It features a 7 inch touchscreen from which users can control every aspect of the printer. Automated calibration and levelling reduces operator input, while a wide variety of sensors give live feedback on machine performance. A material bay contains two active XL spools and can store two more with precise moisture control.
Continuous Fiber Reinforcement, now with ULTEM™ 9085.
The “ULTEM™ and 9085 trademarks are used under license from SABIC, its affiliates or subsidiaries.
Composite 3D Printing Process
3D Printing Software Meets Production Management
Eiger is Markforged’s do-it-all solution for building your additive toolchain. Collaborate on parts across teams and kick-off prints globally on a simple to use, continuously improving platform.
